High-Speed 8-Color Rotogravure Printing Machine
- Colors
- 8 color
- Max printing width
- 1250mm
- Max material width
- 1300mm
- Printing material
- BOPP, OPP, PET, PE, CPP, PVC, PP, Paper
Product Introduction
The ZXN-B1250 series is an 8-color rotogravure printing machine designed for high-speed printing on flexible packaging materials. It supports BOPP, OPP, PET, PE, CPP, PVC, PP and paper, making it suitable for food packaging, daily-use packaging, labels and other roll-fed printed products.
The series provides a maximum material width of 1300 mm and a maximum printing width of 1250 mm. The ZXN-B1250C reaches printing speeds up to 200 m/min, while the ZXN-B1250ES-260 supports speeds up to 260 m/min. Vertical and horizontal registration accuracy is specified at ±0.1 mm.
The machine is intended for converters requiring multi-color continuous printing, stable web handling and consistent registration at industrial production speeds. Model selection should be based on the required printing speed, substrate, color count, cylinder repeat, drying configuration and production volume.
Parameters
| MAIN TECHNICIAN VARIABLES | ZXN-B1250C | ZXN-B1250ES-260 |
|---|---|---|
| Colors | 8 | 8 |
| Max Printing Width | 1250mm | 1250mm |
| Max Material Width | 1300mm | 1300mm |
| Printing Material | BOPP, OPP, PET, PE, CPP, PVC, PP, Paper | BOPP, OPP, PET, PE, CPP, PVC, PP, Paper |
| Mechanical Speed | 250m/min | 300m/min |
| Printing Speed | 200m/min | 260m/min |
| Register Precision Vertical And Horizontal | ±0.1mm | ±0.1mm |
| Unwind Diameter | 600mm | 600mm |
| Rewind Diameter | 600mm | 600mm |
| Paper Core Diameter | 3inch | 3inch |
| Printing Cylinder Diameter | 100-400mm | 100-400mm |
| Machine Power | 210kw | 260kw |
| Dimension | 18500×3800×3000mm | 20000×4100×3200mm |
| Machine Weight | 34000kg | 42000kg |
Application Examples
BOPP and PET Packaging Printing
Laminated Packaging Material
BOPP and PET Packaging Printing
Flexible Food Packaging Film
What materials can the ZXN-B1250 series print?
A
The ZXN-B1250 series is designed for roll-fed flexible packaging materials including BOPP, OPP, PET, PE, CPP, PVC, PP and paper. Material suitability should be confirmed according to substrate thickness, surface treatment, ink system, drying requirements and the intended packaging application.
How many colors can the machine print?
A
The standard configurations shown on this page support up to eight printing colors. The machine is suitable for multi-color packaging graphics, brand designs, text and detailed images that require continuous roll-to-roll gravure printing.
What is the maximum printing speed?
A
The ZXN-B1250C supports printing speeds up to 200 m/min, while the ZXN-B1250ES-260 supports speeds up to 260 m/min. Actual production speed depends on the substrate, ink, color coverage, drying performance, cylinder repeat and registration requirements.
What material and printing widths are supported?
A
The maximum material width is 1300 mm and the maximum printing width is 1250 mm. The required web width, edge allowance and finished package dimensions should be confirmed before selecting the machine configuration.
What registration accuracy can be expected?
A
The specified longitudinal and transverse registration accuracy is ±0.1 mm. Actual performance depends on substrate stability, tension control, cylinder condition, operating speed, web guiding and production settings.
What is the difference between ZXN-B1250C and ZXN-B1250ES-260?
A
Both models support eight colors, a 1250 mm printing width and a 1300 mm material width. The ZXN-B1250C has a maximum printing speed of 200 m/min, while the ZXN-B1250ES-260 reaches up to 260 m/min and has a larger installed power and machine footprint. Model selection should be based on required output, available factory space, power supply and production volume.
When should I choose gravure instead of flexo printing?
A
Gravure printing is generally suited to long production runs, high-speed web printing, detailed graphics and consistent multi-color reproduction on flexible packaging films. Flexographic printing may be more suitable for shorter runs, simpler graphics or applications where lower cylinder investment and faster job changes are priorities.
What installation and technical support are available?
A
Zhengxin can provide installation guidance, commissioning support, operator training, maintenance instructions and remote troubleshooting according to the order and destination. On-site service arrangements, warranty terms, spare parts and travel costs should be confirmed in the sales contract.
